Products - X10 Air Drills

Optional rear wheel rake to prevent smooth surface being left behind to reduce chances of capping. Tines can be adjusted in height and angle to suit conditions. Can be easily folded over to be ‘out of work’ or for transport.

A choice of drag, single or double arm coverers with adjustable lower half to set distance between the arm and the line of seed. The working depth of the arm and the downforce of the arm can all be adjusted. The arm can also be latched out of work if not required.

Weight take off spring allows up to 60kg of reduced downforce on the row.

Clod Deflector (not shown) – an optional floating clod deflector in front of the front wheel is available to move larger clods or stones out of the row prior to the front wheel and is available in two width options 150mm or 190mm.

Choice of hoppers capacities – here shown with a narrower hopper and extension.

Row unit latch up via simple mechanism that can be operated by single person.

Reliable 2 stage chain drive.

Choice of 145mm diameter seed press wheels in solid stainless or with a rubber tyre complete with sprung scrapers. Available to match all multiline setups where depth can be set or wheels latched up out of work via the chain adjustment system.

Latest version of the Stanhay metering unit optimised for multiline line work featuring a ‘knife edge’ seed ejection system. The metering unit can be opened easily without the need for tools.

Infinitely adjustable depth control over a 90mm range.

Manually operated row unit clutch in an easily accessible location to disengage rows in seconds.

Choice of 4 interchangable final drive sprockets to acheive different seeding rates on different rows: -25% / +6% / +17%.

‘Long’ parallel link for precise ground following.

Weight of row spread evenly over front and rear wheels.

Choice of rubber, stainless or cage wheels all complete with sprung scrapers.
